A Myriad of AutoCAD! by CADLearning | Jun 17, 2021 Welcome to your A Myriad of AutoCAD! TRUE or FALSE: Exploding a block reduces the instance of the block back into its individual components. TRUE FALSE None What is the resulting behavior of a layer when you set its Layer State to No Plot? The layer can NOT be seen in the drawing and will NOT print. The layer CAN be seen in the drawing but will NOT print. The layer will NOT print ONLY in the current viewport. The layer will NOT print in the ACTIVE viewport. None The example in the image shows how the center of a circle can be located using which of the following? an Object Snap Track by Center a Two-Point Object Snap Track by Midpoints an Object Snap Track from one point with Polar Angles an Object Snap Track from two points with Polar Angles None When you click the arrow adjacent to the Polar Tracking tool on the Status bar, a list of numbers appears. What are these numbers? Additional Polar Angle Settings Polar Tracking increments default Polar Angle measurements Polar Angle Settings None Before you can draw new geometry on an existing Layer, you must first do what? turn the Layer on set the Layer Current thaw all Frozen Layers unlock the Layer None Polylines are considered to be complex objects because of their unique properties. Which of the following statements regarding polyline properties is FALSE? A polyline consists of multiple segments unified as a single object. Polylines are created on their own layer. Polylines have their own Edit command. Polylines can be made of lines and/or arcs with varying widths. None How do you alternate between the Trim command and the Extend command? use the shortcut menu click with the left mouse button when done right-click or press ENTER on the keyboard press and hold the SHIFT key None TRUE or FALSE: The Undo and Redo tools on the multiline text editor contextual ribbon have the same effect as the Undo and Redo tools on the Quick Access Toolbar. TRUE FALSE None What is the name of the interface component indicated by number “3” in the image? Status bar File tabs Navigation bar InfoCenter toolbar None What, precisely, does the Select Similar tool select? all objects on the same layer as a selected object all objects with the same linetype as a selected object all objects of the same type and whose properties match a selected object all objects except those matching a selected object None How do you change workspaces? click Workspace Switching on the Status bar right-click and choose the workspace from the shortcut menu click Switch Windows in the View ribbon type the name of the workspace in the Command line None Which of the following procedures will NOT allow you to turn on the visibility of the Model and Layout tabs? On the Options dialog, Display tab, select the Display Layout and Model Tabs checkbox. On the View ribbon, Interface panel, click the Layout Tabs tool. Change the value of the LAYOUTTAB system variable. In the Application Status Bar menu, toggle the Display Layout and Model Tabs option. None TRUE or FALSE: You can NOT use grips to mirror objects. TRUE FALSE None You can use the Open from Web & Mobile tool to open drawing files stored in which of the following locations? Dropbox OneDrive A360 all the above None TRUE or FALSE: You can always convert a drawing between systems of measurement by scaling the drawing. TRUE FALSE None Which of the following methods does NOT allow you to repeat the last-used AutoCAD command? press the SPACEBAR press the Enter key right-click the Command line choose Repeat from the right-click cursor menu None When creating a rectangle based on its area, what values must you specify? area, length, AND width area AND length OR width area, length OR width, AND direction any of the above None When you add a continued or baseline dimension, by default, the dimension uses which style? the dimension style you specify the current dimension style the dimension style and layer of the selected dimension the DIMCONTINUE dimension style None Which procedure controls the display of Tool Palettes? right-click the Tool Palettes title bar Options dialog, Display Palettes setting Display Transparency tool View ribbon, View Palettes options None When you use the block insertion gallery to quickly insert blocks into a drawing, how are those blocks inserted, by default? They insert at a different scale and rotation angle that you must specify They insert at their default scale, but you must specify their rotation angle. They insert at a scale that you must specify, but at their default rotation angle. They insert at their default scale and rotation angle. None Time's up Submit a Comment Cancel replyYou must be logged in to post a comment.
